Multi RS Solar - Hybrid Inverter/Charger - Dual Tracker

Multi RS Solar 48/6000/100-450/100 Dual Tracker

The Multi RS Solar 48/6000 is a 48V 6kVA Inverter/Charger with two independent 3kWp PV 450V MPPT tracker inputs for 6kWp PV total.

Thanks to high-frequency technology and a new design, this powerful inverter weighs only 11kg. In addition to this, it has excellent efficiency, low standby power, and very quiet operation.

The display reads battery, inverter, and solar parameters. The same parameters can be accessed with a smartphone or other Bluetooth-enabled device using the VictronConnect app.

In mid-2023, the Multi RS was revised from a single MPPT tracker to a dual MPPT tracker model.

Note: Requires installation by an electrician.

Operating modes:

• Hybrid mode: Stores excess solar energy in a battery, to be used during the night or periods of high demand. Supplies additional power from the battery when demand exceeds grid capacity.
• Backup mode: Switches to backup mode during a grid outage.
• Off-grid mode: Operates without a grid connection.
• Generator mode: Controls the generator to minimize run-hours. Supplies additional power from the battery when demand exceeds the capacity of the generator.

PowerControl and PowerAssist - Boosting the capacity of the grid or a generator: A maximum grid or generator current can be set. The Multi RS will then take account of other AC loads and use whatever is extra for battery charging, thus preventing the generator or grid from being overloaded (PowerControl function).

PowerAssist takes the principle of PowerControl to a further dimension. Where peak power is so often required only for a limited period, the Multi RS will compensate for insufficient generator or grid power with power from the battery. When the load reduces, the spare power is used to recharge the battery.

Display, Bluetooth, and VictronConnect app: The display reads battery, inverter, and solar parameters. The same parameters can be accessed with a smartphone or other Bluetooth-enabled device using the VictronConnect app.

Extendable PV capacity, both AC-coupled and DC-coupled: The integrated 6 kWp PV capacity can be extended by adding solar chargers to the system. Alternatively, the PV capacity can be extended by installing PV inverters, of which the output power will be automatically controlled by the integrated frequency shift power control.

Communication ports: VE.Can connection to a GX device for system monitoring, data logging, and remote firmware updates. VE.Direct connection to a GlobalLink 520 for remote data monitoring.

I/O Connections: Programmable relay, temperature sensor, and voltage sensor connections. The remote input can also be configured to accept the Victron smallBMS.
